UniCarriers 1F1 - Page 186

184
Mast Name
Maximum Fork Height
in (mm)
Free Lift
without
Backrest
in (mm)
Tilt Angle
Forward/Backward
Overall Height
Lowered Mast Position
in (mm)
Extended Mast Position
in (mm)
Top of OHG Mast (OHL) With Backrest Without Backrest
THREE STAGE
(Full Free 3F)
3F385 152 (3850) 56.1 (1420) 5/5 82.1 (2085) 76.7 (1950) Not Available
3F430 169 (4300) 62.0 (1570) 5/5 82.1 (2085) 82.6 (2100) Not Available
3F475 187 (4750) 67.3 (1705) 5/5 82.1 (2085) 87.9 (2235) Not Available
3F515 203 (5150) 72.2 (1830) 5/5 82.1 (2085) 92.8 (2360) Not Available
3F550 217 (5500) 79.7 (2020) 5/5 82.1 (2085) 100.3 (2550) Not Available
3F600 236 (6000) 89.6 (2275) 5/5 82.1 (2085) 110.1 (2800) Not Available
3F650 256 (6500) 99.4 (2520) 5/5 82.1 (2085) 120.0 (3050) Not Available
3F700 276 (7000) 109.3 (2775) 5/5 82.1 (2085) 129.8 (3300) Not Available
THREE STAGE
(Optiview 3V)
3V385 152 (3850) 49.4 (1250) 5/5 82.1 (2085) 76.9 (1955) Not Available
3V430 169 (4300) 55.3 (1400) 5/5 82.1 (2085) 82.8 (2105) Not Available
3V470 185 (4700) 61.2 (1550) 5/5 82.1 (2085) 88.1 (2240) Not Available
3V505 199 (5050) 66.5 (1685) 5/5 82.1 (2085) 93.0 (2365) Not Available
3V555 219 (5550) 71.5 (1815) 5/5 82.1 (2085) 100.5 (2555) Not Available
3V600 236 (6000) 78.9 (2000) 5/5 82.1 (2085) 110.3 (2805) Not Available
3V650 256 (6500) 88.8 (2255) 5/5 82.1 (2085) 120.2 (3055) Not Available
3V700 276 (7000) 98.6 (2500) 5/5 82.1 (2085) 130.0 (3305) Not Available
