Unify OpenStage User Manual

c04.fm
A31003-S2000-R102-16-7620, 02/2016
Provisioning Service, Developer’s Guide
141
Nur für den internen Gebrauch Phone Parameters - Administration
System
Parameters send-url-query
<index>
String Default: NULL One or more key/value
pairs in the format
<key>=<value> to be
added to the request. If
there are more than one
parameters, they are sep-
arated by an ampersand
(&). Please note that, for
the WPI, the ampersand
must be represented by
&amp;.
Method send-url-
method
<index>
Enumer-
ation
0=get;
1=post
Default: 0
HTTP method to be used.
If GET is selected, the ad-
ditional parameters and
the user id/password
are part of the URL. If
POST is selected, these
data form the body of the
message.
Web server user
ID
send-url-user-
id<index>
String Default: NULL User ID to be sent to the
web server, in case au-
thentication is required.
Web server pass-
word
send-url-
passwd
<index>
String Default: NULL Password to be sent to
the web server, in case
authentication is required.
LED controller
URI
stimulus-led-
control-uri
<index>
String Default: NULL This SIP URI will receive
status notifications (SIP
NOTIFY) from a SIP
server. The LED is
switched on or off accord-
ingly.
Push support send-url-push-
support
<index>
Boolean true/false
Default:
false
If set to true, the LED is
controllable by a combi-
nation of an HTTP push
request and an XML doc-
ument. For further infor-
mation, see the XML Ap-
plications Developer’s
Guide.
Available with OpenStage
V2R2.
WBM Name Item name Type Values Description

Unify OpenStage Specifications

General

Display	Graphical LCD
Connectivity	Ethernet
Supported Protocols	SIP
Power over Ethernet	802.3af (PoE), depending on the specific model
Supported Codecs	G.711, G.729
Speakerphone	Yes
Headset Port	Yes
USB Port	No
Bluetooth	No
Humidity	10% to 90% non-condensing
