Unify OpenStage User Manual

c04.fm
A31003-S2000-R102-16-7620, 02/2016
Provisioning Service, Developer’s Guide
89
Nur für den internen Gebrauch Phone Parameters - Administration
Applications
Auto start XML-app-
auto-start
<index>
Boolean true/false
Default: false
Determines whether the
application is automati-
cally started in the back-
ground or only when first
selected.
Available with firmware
version V2.
Use proxy XML-app-
proxy-
enabled
<index>
Boolean true/false
Default: false
Enables or disables the
use of a proxy for commu-
nication with the server
hosting the application.
XML Trace en-
abled
XML-app-
remote-debug
<index>
Boolean true/false
Default: true
Enables or Disables the
debugging function. If dis-
abled, the phone will send
specific debug informa-
tion to a specified server.
Debug program
on server
XML-app-
debug-prog-
name
<index>
Text.
Max. 100
charac-
ters.
Default: NULL
The relative path to a spe-
cial service, or program,
that receives the debug
information created by
the phone.
Number of tabs XML-app-num-
tabs<index>
Integer 0 to 3
Default: 0
Number of internal tabs
for an XML application.
To make an application
with internal tabs work,
one of the application
names (Tab 1...3 Applica-
tion Name) must be the
same as the overall appli-
cation name.
All tabs Start XML-app-all-
tabs-start
<index>
Boolean true/false
Default: false
Determines whether all
tabs of the application or
only the first tab is started
on application startup.
Only meaningful for appli-
cation with 2 or 3 tabs.
Available with firmware
version V2.
WBM Name Item name Type Values Description

Unify OpenStage Specifications

General

Display	Graphical LCD
Connectivity	Ethernet
Supported Protocols	SIP
Power over Ethernet	802.3af (PoE), depending on the specific model
Supported Codecs	G.711, G.729
Speakerphone	Yes
Headset Port	Yes
USB Port	No
Bluetooth	No
Humidity	10% to 90% non-condensing
