Uninet iColor User Manual

39
Lubrication Schedule
COATING UNIT/IMPRESSION ROLLER GEARS - It is very important to Grease the Coating Unit
Gears, Impression Roller Gear and Optional Oscillating Roller every 80 - 100 hours.
DRIVE SPROCKETS - It is very important to Grease the NOP side Drive Sprockets at least twice a
year. Please Note you must remove the side covers to access these Sprockets. Below is an image of
the NOP Side Drive Sprocket.
Coating Unit Gear
Impression Roller Gear
Figure - Lubrication Locations
Figure - NOP Side Drive Sprocket
NOP Side Drive Sprocket
