Laser Cartridge Installation – CO2 Only Platforms
1. Make sure that your laser system power cord is not plugged in at this time. Open the rear laser cover
using the latches on top of the laser cover. Some laser systems are shipped with keyed locks so make
sure the latches are unlocked.
Note: Access latches for the laser cover are lockable. If you lose your keys, please contact our Customer
Service Team at 480-609-0297 (USA), +43 1 402 22 50 (Austria), +81 (45) 224-2270 (Japan) or e-mail us
at support@ulsinc.com
for new keys.
2. Locate the mounting blocks (1), the laser latches (2) and alignment forks (3). Notice that the alignment
fork has a groove (6) located between two blocks, one short (4) and one tall (5).
