Page 24
49668501 Rev. D Radial 8, 88, HT Feeders (Dispensing Heads)
This document supports Dual, Triple, and Quad Span Feeder Assemblies (Dispensing Heads)
2. Disconnect the refire assembly (11) from the cover. Remove the cap
screws (8) that secure the cover (9) to the housing.
3. Remove the cap screws (4) that secure the cylinder and valve unit to
the rear of the feeder housing (5). Disengage the rear driver (6) from
the main driver (7).
NOTE
The main driver assembly (7) and the carrier assembly (12) must be
removed (and installed) together. This prevents damage or loss of the
spring (13) on the bottom of the carrier assembly.
4. To remove the drive assembly, the retainer ring (21) that secures the
drive pin (14) to the link (22) on the ratchet assembly (29), must be
removed. When removing the driver assembly (7) with the carrier
assembly (12), ensure the spring (13) on the bottom of the carrier
assembly is not lost.
