Illustrated Parts Breakdown
6.2
Section
AB46 Work Platform6-26
ENGINE ASSEMBLY, AB46
KUBOTA GAS
68661-000
ITEM PART DESCRIPTION QTY.
1 67615-000 ENGINE, KUBOTA GAS 1
2 68668-000 PUMP, VARIABLE DISPLACEMENT A10VG 1
3 63941-000 SOLENOID, THROTTLE 1
4 12739-099 HOSE, FUEL LINE 4.5 FT
5 20541-003 HOSE CLAMP 6
6 REF FUEL FILTER, INLINE 1
7 27972-000 SOLENOID, STARTER RELAY 1
8 11252-006 SCREW HHC 1/4-20 X 3/4 22
9 68536-000 BRACKET, ENGINE MOUNT GAS 2
10 REF AIR CLEANER AND HOSES 1
11 11941-015 FITTING10MB-10MJ 1
12 11254-008 SCREW HHC 3/8-16 X 1 2
13 68722-000 WELDMENT, MUFFLER SPACER 1
14 REF COIL, IGNITION 1
15 11934-027 FITTING, 90° 8MB- 4MJ 1
16 67695-000 SPACER 2
18 11937-007 FITTING, 90° 12FJX-12MJ 1
19 68708-000 BRACKET, SOLENOID WELDMENT 1
20 11934-019 FITTING 16MB-16MJ 90° 1
21 11252-004 SCREW, 1/4-20 X 1/2LG 10
22 11238-004 WASHER, SPLIT LOCK 1/4 10
23 68747-001 HOSE, AIR INTAKE-GAS 1
25 68812-000 SPLIT FLANGE KIT #12 S FX10 2
26 11941-016 FITTING 10MB-12MJ 1
27 68669-000 PUMP, GEAR TYPE 1
28 11937-003 FITTING 90° 6MJ-6FJX 2
29 20541-013 HOSE CLAMP 4
30 11252-010 SCREW HHC 1/4-20UNC X 1 1/4 1
31 11240-004 WASHER FLAT STD 1/4 18
32 11238-004 WASHER SPLIT LOCK 1/2 2
33 11248-004 NUT HEX 1/4-20 ESNA 15
34 67617-040 KTR BELL HOUSING KIT 1
35 11256-010 SCREW HHC 1/2-13UNC X 1-1/4 2
36 REF. MUFFLER 1
39 11240-006 WASHER FLAT STD 3/8 4
40 63946-030 SCREW HHC M10 X 1.25 GR5 X 30MM 12
41 REF SCREW (SUPPLIED W/ AIR CLEANER) 2
42 REF SCREW MANIFOLD (SUPPLIED W/ ENGINE) 4
43 11253-010 SCREW, HHC 5/16-18 UNC X 1 1/4 4
44 11273-005 NUT, HEX. JAM 5/16-18 UNC 4
45 11238-005 LOCK WASHER, SPLIT RING 4
46 REF ELECTRIC FUEL PUMP 1
47 20495-004 NUT, HEX. JAM 1/4-28 UNF 3
48 30624-019 CHOKE ANGLE 1
49 30624-020 CHOKE ROD 1
50 30624-008 CHOKE SOLENOID BRACKET 1
51 11240-007 WASHER FLAT STD 7/16 12
53 03142-001 FITTING 2MP-2FP 1
54 63945-001 OIL PRESS SWITCH 1
56 68629-000 BRACKET, FUEL PUMP 1
57 11937-006 FITTING, 90° 10FJX-10MJ 1
58 11248-006 LOCKNUT, HEX. 3/8-16UNC ESNA 2
60 68770-001 TAIL PIPE (GAS/PROPANE) AB46 1
62 67615-043 ENGINE ACCESSORY KIT 1
63 67615-041 THERMOSTAT KIT 1
64 68779-000 VALVE, CHECK 2
65 67599-000 SOLENOID, 1
66 20731-005 CHAIN 1
67 68630-006 SPRING LINKAGE 1
68 11847-004 YOKE END 1
69 67807-000 SOLENOID BKACKET 1
101 29602-026 CONN RING #2 3/8 DIA 3
102 29601-039 CONN RING 12-10 GA. 5/16 2
103 29601-013 CONN RING 16-14 GA. # 10 7
104 29620-002 BUTT CONNECTOR 14-16 GA. 2
105 29931-003 CONN FEMALE PUSH 16-14 GA. 1/4 2
106 29478-099 WIRE 16 AWG RED/BLK 2.2 FT
107 29453-099 WIRE 16 AWG ORG 2 FT
108 REF. TUBING HEAT SHRINK 1/4" REF
109 29480-099 WIRE 10 AWG RED 1 FT
110 29601-008 CONN RING 18-22 GA 5/16 4
111 29451-099 WIRE 16 AWG WHT 5 FT
112 29470-099 WIRE 12 AWG RED 4 FT
113 29472-099 WIRE 12 AWG BLK 3 FT
114 29456-099 WIRE 16 AWG YEL 3 FT
115 29452-099 WIRE 16 AWG BLK 6 FT
116 29457-099 WIRE 16 AWG GRN 4 FT
117 29479-099 WIRE 16 AWG WHT/BLK 3.5 FT
118 29450-099 WIRE 16 ASW BLU 4.5 FT
119 68762-000 PIN - CONTACT 8
120 68762-001 SOCKET - CONTACT 8
121 68764-000 PLUG - SEALING 12-14 GA. 8
122 68761-001 LOCK WEDGE - PLUG 1
123 68761-000 LOCK WEDGE - RECEPTACLE 1
124 68760-000 PLUG - CONNECTOR 1
125 68760-001 RECCPTACLE - CONNECTOR 1
ITEM PART DESCRIPTION QTY.
