Illustrated Parts Breakdown
6.2
Section
AB46 Work Platform6-20
LOWER BOOM LINKAGE ASSEMBLY
AB46
68323-000
ITEM PART DESCRIPTION QTY.
1 68330-000 TURRET ASSEMBLY REF
2 68397-000 RISER POST WELDMENT 1
3 68399-000 TENSION LINK WELDMENT 1
4 68400-000 1ST. TENSION RAIL WELDMENT 2
5 68543-000 2ND. TENSION RAIL WELDMENT 1
6 68412-000 FRONT RISER WELDMENT 1
7 68415-000 2ND. RISER BOOM WELDMENT 1
8 68417-000 1ST. RISER BOOM WELDMENT 1
9 68475-000 PIN, 1.75 DIA. X 12.25 LG. 4
10 68477-001 PIN, 1.75 DIA. X 3.75 LG. 4
11 68451-000 CYLINDER, BOOM RAISE 1
* 68451-010 SEAL KIT, BOOM 1
12 68450-000 CYLINDER, BOOM RISER 1
* 68450-010 SEAL KIT, RISER 1
13 68477-007 PIN, 1.75 DIA. X 5.00 LG. 2
14 68796-002 PIN, 1.50 DIA. X 8.50 LG. 1
15 68796-001 PIN, 1.50 DIA. X 12.25 LG. 1
16 68477-005 PIN, 1.75 DIA. X 13.75 LG. 1
17 68477-003 PIN, 1.75 DIA. X 19.50 LG. 1
18 68477-002 PIN, 1.75 DIA. X 16.50 LG. 1
19 68477-006 PIN, 1.75 DIA. X 8.63 LG. 1
20 68794-000 PIN, 1.75 DIA. X 5.88 LG. 2
21 62642-034 BUSHING, Ø 1.75 X 2 (28DU32) 14
22 62642-028 BUSHING, Ø 1.75 X 1 (28DU16) 4
23 62642-031 BUSHING, Ø 1.75 X 1.50 (28DU24) 16
24 62642-036 BUSHING, Ø 1.50 X 1.25 (24DU20) 4
25 65214-000 ROD END (PIN RETAINER) 3/8" 4
26 11254-006 SCR, HHC 3/8-16UNC X 3/4 14
27 11238-006 LOCKWASHER, SPLIT RING 3/8 14
28 11254-012 SCR, HHC 3/8-16UNC X 1 1/2 2
29 11254-028 SCR, HHC 3/8-16UNC X 3 1/2 3
30 11248-006 LOCKNUT, HEX 3/8-16UNC (ESNA) 6
31 11254-024 SCR, HHC 3/8-16UNC X 3 1
32 68454-000 MASTER CYLINDER 1
* 68454-010 SEAL KIT, MASTER 1
33 68477-008 PIN, 1.75 DIA X 4.75 LG. 2
34 68660-000 REST PAD 1
35 66516-004 CAP, 4" 1
36 11941-004 FITTING, STR 6MB-4MJ 6
37 11932-001 FITTING, 45° 4FJX-4MJ 2
40 65214-001 ROD END (PIN RETAINER) 1/2" 12
41 11254-010 SCREW HHC 3/8-16UNC X 1-1/4" 12
42 11254-014 SCREW HHC 3/8-16UNC X 1-3/4" 1
43 11709-014 SCREW RD HD 10-24 X 1-3/4" 2
44 11248-003 NUT, 10-24 ESNA 2
45 68556-000 SWITCH 1
46 29925-000 STRAIN RELIEF 1
47 68556-001 LEVER 1
48 11739-020 ROLL PIN 3/8 X 2-1/2 2
49 11253-010 SCREW HHC 5/16-18 UNC X 1 1/4 4
50 11248-005 LOCKNUT HEX 5/16-18 UNC ESNA 4
51 14996-005 WASHER 5/16 SAE FLAT 8
52 68778-000 VALVE, COUNTERBALANCE 4
* Not Shown
