3-1AB46 Work Platform
Maintenance
3.0 Introduction
Be sure to read, understand and follow all
information in the Operation Section of
this manual before attempting to operate
or perform service on any AB46 Work
Platform.
This section contains procedures for the operation
inspection, adjustment, scheduled maintenance, and
repair/removal of the AB46.
Section 2.0
will aid in understanding the operation and
function of the various components and systems of the
AB46 and help in diagnosing and repair of the machine.
Refer to Table 3-1, Preventative Maintenance Checklist,
for recommended maintenance intervals.
NOTE: Torque all hardware to torques listed on page
3-32 unless otherwise specified.
TERMINOLOGY
TERMINAL BLOCKS: Located in upper and lower
control boxes. Designated by TB##. (##) designates
the number of the block which is written on the termi-
nal block. "R" right or "L" may follow the number.
WIRE COLOR: Indicated by color/color. First color
refers to insulation color and second color indicates
stripe. If second color is not given there is no stripe.
FORWARD: Front of machine indicated by yellow
arrows on chassis.
AFT: Rear of machine indicated by orange arrows on
machine.
GENERAL PROCEDURES
CONTACT BLOCKS: Removed by inserting a flat
screwdriver into the slot at either end of block and
prying outward. Installed by pressing into an empty slot.
SWITCH MOUNT BASE: Assembled to back of switch
actuator. Removed by rotating the small black lever
counterclockwise and lifting off base.
TERMINAL BLOCKS: Remove wires by inserting a small
flat bladed screwdriver into square beside wire. Install
wires by stripping 1/2" of insulation, inserting screw-
driver in square and inserting wire. Be sure no strands
are bend backwards. Replace wires with same rating
and type.
3.0
SPECIAL TOOLS
The following is a list of special tools which may be
required to perform certain maintenance procedures on
the AB46 work platform.
0-1000 PSI Hydraulic Pressure Gauge
with Adapter Fittings (UpRight P/N 014124-010)
0-3000 PSI Hydraulic Pressure Gauge
with Adapter Fittings (UpRight P/N 014124-030)
0-6000 PSI Hydraulic Pressure Gauge
with Adapter Fittings (UpRight P/N 014124-060)
0-30 Gallon Hydraulic Flow Meter
With 0-3000 P.S.I. Simulated Load and Adapter
Fittings (UpRight P/N 67040-000)
Adapter Fitting (UpRight P/N 063965-002)
Inclinometer (UpRight P/N 010119-000)
Crimping Tool (UpRight P/N 028800-009
Terminal Removal Tool (P/N 028800-006)
3.1 Preventative Maintenance
(Table 3-1)
The complete inspection consists of periodic visual and
operational checks, together with all necessary minor
adjustments to assure proper performance. Daily
inspection will prevent abnormal wear and prolong the
life of all systems. The inspection and maintenance
schedule is to be performed at regular intervals. Inspec-
tion and maintenance shall be performed by personnel
who are trained and familiar with mechanical and
electrical procedures.
Before performing preventative mainte-
nance, familiarize yourself with the opera-
tion of the machine.
Always block the elevating assembly when-
ever it is necessary to perform mainte-
nance while the platform is elevated.
