Upright AB46 I User Manual

Illustrated Parts Breakdown
6.2
Section
AB46 Work Platform6-2
FINAL ASSEMBLY, AB46
GAS
68301-000
ITEM PART DESCRIPTION QTY.
1 68304-000 BASIC ASSY. AB46-G 1
2 68339-002 CONTROLLER INSTL-GAS DOM 1
3 68335-001 LABEL KIT/INSTL-GAS 1
4 68336-001 HOSE KIT/INSTL-I/C NOT SHOWN 1
6 29945-014 LEVEL SENS P-Q GASDOM NOT SHOWN 1
7 68340-002 HYDRAULIC SCHEMATIC AB46 I.C. REF
8 68341-001 ELEC SCHEMATIC AB46 GAS DOMESTIC REF
201 29433-099 CABLE, 24 COND. 18 GA. 11FT
202 29433-099 CABLE, 24 COND. 18 GA. 63 FT
203 29434-099 CABLE, 3-10 GA. / 9-14 GA. 11FT
204 29434-099 CABLE, 3-10 GA. / 9-14 GA. 63 FT
205 29433-099 CABLE, 24 COND. 18 GA. 63 FT
206 29447-099 WIRE, 3 COND. 16 GA. 13 FT
207 29447-099 WIRE, 3 COND. 16 GA. 11 FT
208 29498-099 WIRE, 4 COND. 16 GA. 11 FT
210 29496-099 WIRE, 2 COND. 16 GA. 26 FT
211 29496-099 WIRE, 2 COND. 16 GA. 37 FT
212 29496-099 WIRE, 2 COND. 16 GA. 5 FT
213 68814-000 TERMINAL, PIN 6
214 29610-006 TERMINAL, FORK 18-16 #6 41
301 29601-005 TERMINAL, RING 18-22 GA. #10 22
302 29931-003 TERMINAL, FEM. PUSH-ON 16-14 15
303 14914-001 TERMINAL, MALE PUSH-ON 18-22 .25 3
401 29440-099 WIRE, 3 COND. 12 GA. SO. 2 FT
402 29490-099 WIRE, 2 COND. 16 GA. SO. 8 FT
403 29496-099 WIRE, 2 COND. 16 GA. 2 FT
