Illustrated Parts Breakdown

6.2

Section

AB46 Work Platform6-24

TURRET ASSEMBLY

AB46 GAS

68330-001

ITEM PART DESCRIPTION QTY.

TURRET ASSEMBLY

AB46 DIESEL

68330-002

1 68392-000 TURRET POST WELDMENT 1

2 68485-000 STOP WELDMENT 1

3 68319-000 SHIM, 16GA, REST PAD 4

4 68319-001 SHIM, 10GA, REST PAD 4

5 68660-000 REST PAD 2

6 11291-032 SCREW, HHC 5/8-11 X 4 GR 8 24

8 68478-000 TUBE, STL 1"O.D. X .120W X 3.10" LG 1

9 11248-012 NUT, HEX ESNA 3/4-10 ESNA 1

10 11240-012 WASHER 3/4 STL 2

11 68720-002 NEOPRENE SPRING CYLINDER-POLY. 1

12 14099-036 SCREW, HHC 3/4-10 X 4-1/2 1

14 68472-000 SHIM RING 1

15 11248-004 NUT, HEX ESNA 1/4-20 18

18 68656-000 COVER TRIM, GROUND CONTROL 1

19 68653-000 COUNTER WEIGHT, LEFT SIDE 1

20 68652-000 COUNTER WEIGHT, REAR 1

21 68654-000 COUNTER WEIGHT, RIGHT SIDE 1

22 68657-000 COVER TRIM, VALVE BLOCK 1

23 14099-012 SCREW HHC, 3/4-10UNC X 1-1/2 2

24 14918-020 SCREW HHC, 1-8UNC X 2-1/2 6

25 11239-012 WASHER FLAT ASTM 3/4" A325 2

26 11240-016 WASHER FLAT 1" STD 6

27 68328-001 LOWER CONTROL BOX-GAS 1

28 11297-010 BELLEVILLE WASHER 5/8 DIA 24

29 11240-004 WASHER, 1/4 FLAT STD 30

30 29958-001 HORN, 12 VOLT 1

31 68678-024 TUBING, POLYURETHANE 24" 2

32 13336-001 FITTING, GREASE 2

33 68679-003 FITTING, BULKHEAD 2

34 11252-006 SCREW, HHC 1/4-20 X 3/4 16

36 68348-001 VALVE BLOCK ASSY-I/C 1

38 REF DRIVE WORM GEAR (68571) REF

39 68660-001 REST PAD 1

40 68759-000 HINGE,TURRET COVER 2

41 11253-018 SCRW HHC GR5 5/16-18 X 1-1/2 1

42 11253-022 SCRW HHC GR5 5/16-18 X 2-3/4 2

43 68757-002 LATCH, SOUTHCO 2

44 61692-099 GROMMET MATERIAL 10FT

45 11253-012 SCRW HHC GR5 5/16-18 X 1-1/2 8

46 11248-005 NUT HEX 5/16-18 ESNA 12

47 14996-005 WASHER 5/16 FLAT SAE 22

48 11253-006 SCRW HHC GR5 5/16-18 X 3/4 5

49 11238-005 WASHER, SPLIT LOCK 5/16 4

50 11254-006 SCRW HHC GR5 3/8-16 UNC X 3/4 6

51 11238-006 WASHER, SPLIT LOCK 3/8 6

52 14996-006 WASHER, 3/8 FLAT SAE 6

54 68792-000 BRACKET 1

55 68793-000 BRACKET 1
