Illustrated Parts Breakdown
6.2
Section
AB46 Work Platform6-40
1 68349-000 VALVE BLOCK SUB-ASSY. 1
2 11934-001 FITTING, 2062-4-4S 6
3 11240-005 WASHER 5/16 FLAT 2
4 11940-019 90° ELBOW 3/4NPT X 3/4 JIC 1
5 68681-000 FLOW CNTRL,WATERMAN 12C241SP-11/A10 1
6 68683-000 3 POS, 4 WAY, TANDEM CENTER 1
7 68682-000 3 POS, 4 WAY, CLOSED CENTER 4
8 68684-000 3 POS, 4 WAY, MOTOR SPOOL 3
9 60390-020 RELIEF VALVE, 2540 PSI 1
10 60390-021 RELIEF VALVE, 1450 PSI 1
11 63965-001 PLUG, GAGE PORT 2
12 68558-000 DIVERTER VALVE 1
13 68778-000 COUNTERBALANCE VALVE 1
14 68430-000 PISTON, HAND PUMP 1
15 68428-000 LEVER WELDMENT, HAND PUMP 1
16 68429-000 LEVER EXTENSION, HAND PUMP 1
17 68564-001 DETENT BALL / SPRING 1
18 68566-000 PIVOT LINK 1
19 68425-000 MOUNTING PLATE, VALVE BLOCK 1
20 12499-016 SEAL, POLYPAK #12500625 1
21 14334-004 SCREW. SOC. HD. 5/16-18 UNC X 1/2 4
22 15936-005 SCREW, SHOULDER Ø 3/8 X 5/8 LG 1
23 11941-002 FITTING 202702-4-6S 1
24 05154-001 FILTER ASSY. 1
25 14028-008 PIPE NIPPLE, 3/4 SCHD 40 X 4 1
26 11935-013 FITTING 45° 6MB-4MJ 1
27 11935-001 FITTING, 45° SWIVEL EL. 4MB-4MJ 7
29 11934-004 FITTING 90° EL. 6MB-6MJ 1
30 68700-000 HAND GRIP, VINYL 1
31 11934-003 FITTING 2062-6-4S 1
32 11821-004 SCRW BUTT HEAD 1/4-20UNC X 1/2 1
33 11822-006 SCRW BUTT HEAD 5/16-18 UNC X 3/4 2
34 63783-002 LANYARD ASSY 1
35 11941-005 FITTING 202702-6-6S 2
36 15919-000 ORFICE 1
37 68781-001 VALVE 1
38 61827-000 STEEL BALL 7/16 DIA 1
39 68791-000 BRACKET 1
40 29601-012 CONN. RING, 18-14 GA. #8 16
41 29616-002 CONN. FEM. PUSH, .25 1
42 29452-099 WIRE, 16 GA. BLACK 3 FT.
43 11934-026 FITTING 90° 4MB-6MJ 1
VALVE BLOCK ASSEMBLY, AB46
GAS/DIESEL
68348-001
ITEM PART DESCRIPTION QTY.
