Switch Adjustments Section 2 - Service and Repair
Page 2-10 113101-000 MX15 / MX19 | Service Manual
P
ROXIMITY
S
WITCH
Refer to Figure 2-5.
The Proximity Switch is a magnetically activated switch located near the rear of the chassis on the left
side. Its function is determined by the location of the lower elevating assembly tube.
P
ROXIMITY
S
WITCH
F
UNCTION
A red LED at the rear of the switch should be ON when the elevating assembly tube is next to the switch
(the platform is lowered). The Proximity Switch controls the machine operation based upon the proximity
of the elevating assembly tube to the Proximity Switch.
When Elevating:
The Level Sensor is enabled.
The Depression Mechanism is enabled.
Power to the High Speed Circuit is cut, preventing the machine from travel faster than 1,0 km/h
(0.62 mph).
When Completely Lowered:
Power is supplied to the High Speed Circuit, allowing the machine to travel up to 3,7 km/h (2.3 mph).
T
EST
THE
P
ROXIMITY
S
WITCH
WARNING
!
!
Never perform service while the platform is elevated without first blocking the elevating assembly.
DO NOT stand in the elevating assembly area while deploying or storing the maintenance brace.
1. Turn the Chassis Key Switch ON.
The red LED should be ON. If not, the Proximity Switch may be out of adjustment.
2. Elevate the platform until the elevating assembly tube is clear of the Proximity Switch.
The red LED should turn OFF.
3. Deploy the Maintenance Brace.
4. Place a piece of steel next to the Proximity Switch.
The red LED should turn ON. If it was OFF in Step 1, the Proximity Switch requires adjustment.
If the red LED remains OFF, replace the Proximity Switch.
T
EST
H
IGH
S
PEED
C
IRCUIT
1. Elevate the platform 30 cm (12 in.).
2. Turn the Lift/Drive Switch to DRIVE and attempt to drive the machine.
If the machine will drive faster than 1,0 km/h (0.62 mph), adjust or replace the switch.
R
EMOVAL
AND
I
NSTALLATION
1. Deploy the maintenance brace (see “Blocking the Elevating Assembly” on page 2-6).
2. Disconnect the switch leads.
3. Remove the defective switch and install a new one.
4. Adjust the switch-to elevating assembly tube clearance (see “Proximity Switch Adjustment” on
page 2-11).
5. Connect the switch leads.
6. Store the maintenance brace and lower the platform.
