US Cutter MH-721 - USCutter Stand Assembly Guide; Attaching Roller Arms to Columns

1
Needed For
This Step
H (x1) - Right Roller Arm
J(x1) - Right Column
C(x3) - Bolt
B(x3) - Bolt Cap
Attaching the Right Roller
Arm to the outer side of
the Right Column
(outer side will have a
curved edge and will have
larger hole openings)
2
Needed For
This Step
G(x1) -Left Roller Arm
K(x1) - Left Column
C(x3) - Bolt
B(x3) - Bolt Cap
Attaching the Left Roller
Arm to the outer side of
the Left Column
(outer side will have a
curved edge and will have
larger hole openings)
1
