US Cutter MH-721 - Attaching Feet to the Stand Base

US Cutter MH-721
42 pages
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Loading...
3
Needed For This
Step
Assembled right side (roller arm, column)
D(x4) - Long Screw
M(x1) - Foot
Attaching a Foot on
the right side
4
Needed For This
Step
Assembled left side (roller arm, column)
D(x4) - Long Screw
M(x1) - Foot
Attaching a Foot on
the left side
