USAutomatic SENTRY 300 S - 4 Attach Actuator Bracket To Universal Actuator Bracket; 5 Install Linear Actuator To Actuator Bracket

12
Attach Actuator Bracket to Universal Actuator Bracket
Theactuatorbrackethasa3/8”predrilledholethatthelinearactuatorwill
mountto.Thisisthepivotpointforthelinearactuator.Inallcases,the
universalactuatorbracketshouldbealignedlevelwithahorizontalgate
section.(seeMountingSiteReview)
For a Pull to Open installation - thepre-drilledholemustbelocated5”
behindthegatehingeand8”totheinsideoftheproperty.
For a Push to Open installation - thepre-drilledholemustbelocated7”in
frontofthegatehingeand4”tothedrivesideofthehinge.
Thesedimensionsaremeasuredfromthecenterofthegatehinge(pivotpoint).
Hardware needed:
• two3/8”x21/2”shoulderbolts
• two3/8”USSatwashers
• two3/8nylonlocknuts.
1. Attachactuatorbrackettouniversalactuatorbracket.
2. Verifythatactuatorbracketpivotholedimensionislocatedinthe
correctpositionseepage10fordimensions.
3. Tightenboltssecurely.
Install Linear Actuator to Actuator Bracket
Theactuatorcanbemountedintwodifferentpositionsasshown.Installingthe
actuatoronitssidecanallowforhidingitbehindacrossmemberinthegateframe.Thegatesbelow
areshownintheclosedposition.
1. Installnylonwashersandbronzebushingsintorearoflinearactuator.
2. Installthelinearactuatorintoactuatorbracket
3. Securethelinearactuatorinplaceusing3/8x21/2”shoulderboltand
two3/8SAEwashers.
4. Use3/8nylonlocknuttosecure,tightenrmly.
Actuator should swing freely, DO NOT OVER TIGHTEN!
CAUTION:Ifmountingactuatoronitsside,ensureactuatorcasedoes
notcomeincontactwithanyobjects.Mountasshownsothatwidepart
ofmotorcaseandcableisawayfromgate.
4
5
Actuator
Bracket
Pivot
Point
Predrilled
Hole
