Sentry Plug N Go Harness
ThePlugNGoHarnesscomespreinstalledandshouldbeplugged
intothebottomofthechargecontroller.Plugiscolorcoded.Red
connectstopositivebatterypostandBlackconnectstonegative
batterypost.Onceconnected,placeharnessintowirecompartmentto
prepareforbatteryinstallation.
Install Battery
BATTERY REQUIRED FOR OPERATION (Battery not included)
Recommendedbatterytype-12-volt,GroupU-1;sealed
(maintenancefree);30amphourminimum.Thisbatteryis
sometimesdescribedasanon-spillablelawntractorbattery.Battery
physicalsizemustnotexceed9”wide,7”talland53/4”deep.
ThePlugNGoharnesshastwo1/4”ringterminalstoconnectto
bolttypebatterypost.
CAUTION-Donotinstallwetcellbatteryintocontrolbox;thistype
ofbatteryusuallyhasremovablecapsusedforserviceandwillvent
corrosivefumesintocontrolbox.
1.Installthebatteryintothebatterycompartment.
2.ConnectOringterminalsfromharnesstothebattery.
NOTE: Redwiretopositivepostofbattery
 Blackwiretonegativepostofbattery
3.Tightentheboltssecurely(boltsshouldbesuppliedwiththebattery).
10
11
1/4” Ring terminal for battery
Red connects to positive battery post
Black connects to negative battery post
Charge controller connector
15 amp fuse
Gate 1 and Gate 2 linear
actuator power plugs
