USAutomatic SENTRY 300 S - Accessories

28
Sentry Garage Door Receiver
PartNumber030209
ThereceiverprovidedwiththeSentrygateopeneroperatesat433.92MHZand
mightormightnotbecompatiblewithyourgaragedoor.Ifreceiverfrequencyisnot
compatibletheoptional“SentryGarageDoorReceiverkit”canbeeasilyinstalledin
thegarage.
Thekitcontainsreceiver,transformerandawireharnessthateasilyinstallstothe
existinggaragedoor.Onereceiverwillbeneededforeachgaragedoor.Allexisting
transmittersusedforgaragedoorwillcontinuetooperate.Theyarenotbeing
disconnected.Mountinghardwareincluded.
Toprogramopenreceiverboxcover.Placesmallscrewdriverinslottoopen.Press
thelearnbutton.Thenpressthetransmitterbuttonthatwillbeusedtoopenthe
garage.Seegarageopenerforconnectingthe2wiressupplied.
Ifneeded,4buttontransmittersareavailableatwww.sentrygateopener.compart
number030212.
CAUTION:DOORWILLOPERATEWHENRECEIVERISPROGRAMMEDIFSIGNALWIRES
AREATTATCHED.KEEPHANDSCLEAROFMOVINGPARTSTOAVOIDINJURY
Sentry Push to Operate Wireless(Solarfriendlydevice)
PartNumber050510
ThePushtoOperatetransmitterisdesignedforoutdoorwirelessinstallation.Install
toallowoperationofthegateorgaragebysimplypressingthepad.Thebuttonisa
pressuresensitivepad.Pressthepadanaudibletoneisgenerated.Programmingis
identicaltotransmitterprogramming.Installationhardwareisincluded.
7 Day Timer (Solar friendly device)
PartNumber550015
Theoptional7daytimercanbeusedtoopenthegateatapresettimeandiftheauto
closefeatureofthegateoperatorisbeingusedthegatecanthencloseautomatically
atapresettime.Thetimerissuppliedwith3spadeterminalsforeasyconnection.
ConnectwiresfromtimertocontrolboardJ2connectorasfollows:
• J2Pin1(+12vdc)connecttopin1
• J2Pin2(Gnd)connecttopin2
• J2Pin9(NormallyOpen)connecttopin4
Sentry Exit Sensor (Solarfriendlydevice)
PartNumber070310
Thedrivewayexitsensorisamagneticdevicethatinstallsbelow
groundbesidethedrive.Amagneticeldisestablishedwhichwhen
interruptedbyametalobjectwillsendasignaltoopenthegate.This
sensorissuppliedwitha100footcableandistypicallyinstalledinside
thepropertybesidethedrivetoautomaticallyopenthegatewhenacar
passes.Ifmorethan100footofcableisdesireddonotattempttoadd
cable.Thiswillonlycreateproblems.Thistypeofsensorisnotasafety
device.Sensorcanbeorderedwithlongercables.
ItisrecommendedtoinstallthissensorandcableinPVCconduit.
Wireasfollows: Redwire–connecttoJ2pin1
 Shield(braidedwire)–connecttoJ2pin2
 Blackwire–connecttoOpenInput/ExitSensor-N/O
Accessories
