USAutomatic SENTRY 300 S - Control Switch Functions; Operating Gate for the First Time

21
J2 Terminal (AccessoryWiring)
AccessorieswiretotheJ2connector.Insertwireandtightenscrew.
J2 pin functions are as follows:
J2pin1-+12VDCoutputforanyaccessorypowerneeded
 (80mamax).
J2pin2-Groundconnectionforanyaccessoryitem.
J2pin3-PushButtoninput
J2pin4-MonitoredcontactedgeinputN/O
J2pin5-SafetyReversinginput(PhotoEyeN/Oinput)
J2pin6-PhotoEyePoweroutput(+12VDConly)connectphotoeyepowerleadhere.
J2pin7-SolenoidLockPoweroutput(+12VDConly)connectsolenoidlockpowerleadhere.
J2pin8-MonitoredPhotoEye-N/C
J2pin9-OpenInput/ExitSensor-N/O
Control Switch Functions
Switch 1 Autocloseenable–Turnsonthe
autoclosefeature.Gatewillclose
fromanyposition.
DO NOT turn this feature on unless safety
devices are installed (see page 29) for details.
Switch 2 Operatingdirectionreverse–
Turn“ON”forPushtoOpen
installation only.
Switch 3 Gate1enable–Turnson
Gate1connector
Switch 4 Gate2enable–TurnsonGate2
connector
Switch 5 SolenoidLockEnable–Turn“ON”iflockpower(+12vdc)iswiredtocontrolboard.
Switch 6 PhotoEyeEnable–Turn“ON”ifphotoeyepower(+12vdc)iswiredtoJ2.6.Donot
connectphotoeyetobatteryorprematurebatteryfailurewilloccur.
Switch 7 PhotoEyeMonitor-NOTUSED-Mustbe“OFF”foroperation.
Switch 8 ContactEdgeMonitor
Operating Gate for the First Time
Beforeoperatinggateverifythatthegatepathisclearand
freeofobstructions.
Beawaretostopthegateincaseofanemergencysimplydisconnect
thelinearactuatorcable8pinplugfromthecontrolboard.
Gateshouldbeintheopenpositionatthispoint.
Pressthe“Open/CloseCommand”pushbutton.Thegateshouldbeginto
close.Allowthegatetotraveltothefactorypresetstopposition.
20
J2 Terminal
