Making Final Adjustments
OncethegatehastraveledtothestoppositionadjusttheGate1“ExtendLimitMoreorLess”
adjustmentdiallocatedonthecontrolboard.
Turntheadjustmentslightlyclockwisetoclosegatemore,cyclegateandrepeatuntilclosepositionis
correct.Ifgateisadjustedpastthedesiredclosedpositionturntheadjustment
counterclockwiseslightly.
Thencyclethegatetoverifyclosepositioniscorrect.
Install Safety Signs
Mountthe2includedsafetysignsoninsideandoutsideofthegate
areasotheyareclearlyvisible.
Programming Transmitter and Receiver
(model 433DSR2LC):
Operatingfrequency433.92MHz.
Receivercanstoreupto42uniquetransmitterdipswitchcodesettings.
Transmitter Setup:
(It is recommended that the dipswitch code be changed from
the default factory setting)
1.Openthebatterycompartmentdoorandlocatethedipswitches.
2.Changethedipswitchestothesettingsyouprefer,recordforfuturereference
in the table below.
Switch
Position
Switch
1
Switch
2
Switch
3
Switch
4
Switch
5
Switch
6
Switch
7
Switch
8
Switch
9
+
0
-
Transmitter Left Button to Receiver Programming: (standard Open/Stop/Close function)
1. Pressandholdthelefttransmitterbuttondown.Redlightontransmittershouldbeon.
2. Onthereceiver,pushtheP1push-buttonuntilthegreenLDlightcomeson.
3. Releasebothbuttons.Transmitterleftbuttontoreceiverprogrammingiscomplete.
Transmitter Right Button to Receiver Programming:
(Hold-Gate-Open) (Only if auto close timer is enabled)
1. The2-channelreceiverallowsforprogrammingtheP2
relayfrommomentarymode(default)tolatchingmode.
Transmitterrightbuttoncanbeprogrammedtoholdgate
open,over-ridingtheauto-closefeatureifactivated.
Battery
Compartment
Door
23
P1 Button
P2 Button
