Troubleshooting
6-16
4
Raise the paper feed unit A.
5
Remove any jammed originals without tearing them.
Note If the original does happen to tear, remove any loose scraps from inside the document processor.
6
Turn the dial as shown in the illustration to remove the
jammed original.
7
Close the left cover to its original position.
Reset all the originals and start copying again.
Paper Jam in the Optional Finisher
If Paper misfeed in Finisher, lower
Process Tray and remove paper appears and
the jam location indicator shown in the illustration
blinks, a paper jam has occurred in the optional
finisher. Perform the following procedure to remove the
jammed paper.
Important! The drum section inside the main body is sensitive to scratches and contaminants. When removing
paper, be careful not to touch it or scratch it with your watch, ring, etc.
1
Turn the lever to lower the process tray.
A
Paper misfeed in
Finisher,lower Process
JAM80
Tray and remove paper.
To Next Page
