Utax P-4035 MFP Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
1-4-21
0110 Backup memory data error EEPROM
(Control PWB)
1. Turn the main power swtch off and after
5 seconds, then turn power on.
2. Check that the EEPROM on the main
circuit PWB is peroperly installed on the
main circuit PWB and, if not, re-install it.
3. Replace the control PWB and check for
correct operation (see page 2-2-12).
0120 MAC address data error
For data in which the MAC
address is invalid.
EEPROM
(Control PWB)
1. Turn the main power swtch off and after
5 seconds, then turn power on.
2. Check the MAC address on the network
status page.
3. If it is blank, obtain an EEPROM with its
MAC address written from the service
support and install.
4. Replace the control PWB and check for
correct operation (see page 2-2-12).
0130 Backup memory read/write
error (main NAMD)
Flash memory
(Control PWB)
1. Turn the main power swtch off and after
5 seconds, then turn power on.
2. Replace the control PWB and check for
correct operation (see page 2-2-12).
0140 Backup memory data error
(main NAND)
Flash memory
(Control PWB)
1. Turn the main power swtch off and after
5 seconds, then turn power on.
2. Replace the control PWB and check for
correct operation (see page 2-2-12).
0150 Backup memory read/write
error (control PWB)
No response is issued from
the device in reading/writing
for 5 ms or more and this
problem is repeated 5 times
successively.
Mismatch of reading data from
2 locations occurs 8 times
successively.
Mismatch between writing
data and reading data occurs
8 times successively.
EEPROM
(Control PWB)
1. Turn the main power swtch off and after
5 seconds, then turn power on.
2. Check that the EEPROM is peroperly
installed on the control PWB and re-
install it.
3. Replace the control PWB and check for
correct operation (see page 2-2-12).
4. Check the EEPROM and if the data are
currupted, contact the service support.
0160 Backup memory data error
(control PWB)
Reading data from EEPROM
is abnormal.
EEPROM
1. Turn the main power swtch off and after
5 seconds, then turn power on.
2. Execute U021 - memory initializing.(see
page 1-3-22)
3. If the EEPROM data are currupted,
contact the service support.
Code Contents Related parts
Check procedures/
corrective measures

Utax P-4035 MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	40 cpm
Scan to	E-mail, File, Image, USB
Grayscale levels	256
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	200 x 100 DPI
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	- pages per month
Total input capacity	500 sheets
Total output capacity	250 sheets
Duplex media weight	60 - 120 g/m²
Paper tray media types	Envelopes
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Product color	Black, Grey
Market positioning	Business
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
Standard interfaces	Ethernet, USB 2.0
Memory slots	1
Internal memory	512 MB
Compatible memory cards	SD
Sound power level (standby)	53 dB
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	54.7 W
Power consumption (average operating)	680 W

Weight and Dimensions

Depth	455 mm
Width	475 mm
Height	575 mm
Weight	21500 g
