Utax P-4035 MFP Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
1-4-22
0170 Billing counting error
The values on the main circuit
PWB and on the engine do
not match for any of charging
counter, life counter, and
scanner counter.
EEPROM
1. Check that the EEPROMs installed in
the control PWB are correct and, if not,
use the correct EEPROM for the model.
2. If the EEPROM data are currupted,
contact the service support.
Control PWB
Replace the control PWB and check for
correct operation (see page 2-2-12).
0180 Machine number mismatch
Machine number of control
does not match.
Data damage of
EEPROM
1. Confirm the machine data for the control
units by using U004 (see page 1-3-19).
2. If the serial number data of different
models is alternately displayed, install
the correct EEPROM in the PWB of the
wrong serial number data.
3. Contact the Service Support.
0190 Backup memory device
error (control PWB)
Control PWB
Replace the control PWB and check for
correct operation (see page 2-2-12).
0800 Image processing error
JAM010X is detected twice.
Control PWB
Replace the control PWB and check for cor-
rect operation (see page 2-2-12).
0830 FAX control PWB flash pro-
gram area checksum error
A checksum error occurred
with the program of the FAX
control PWB.
FAX software
1. Reinstall the fax software.
FAX control PWB
1. Execute initializing by U600.(Refer to
the FAX service manual)
2. Replace the FAX control PWB.
0840 Faults of RTC
(“Time for maintenance T” is
displayed)
[Check at power up]
The RTC setting has reverted
to a previous state. The
machine has not been pow-
ered for 5 years (compared to
the settings stored periodically
in the EEPROM).
The RTC setting is older than
00:01 on January 1, 2000.
[Checked periodically (in 5-
minute interval) after powered
up]
The RTC setting has reverted
to a state older than the last
time it was checked.
10 minutes have been passed
since the previous check.
Battery
(Control PWB)
1. Make sure that the back-up batteries on
the control PWB are not short-circuited.
2. If the same C call is displayed when
power is switched on and off, replace the
back up battery.
3. If communication error (due to a noise,
etc.) is present with the RTC on the con-
trol PWB, check the PWB is properly
grounded.
Control PWB
Replace the control PWB and check for
correct operation (see page 2-2-12).
Code Contents Related parts
Check procedures/
corrective measures

Utax P-4035 MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	40 cpm
Scan to	E-mail, File, Image, USB
Grayscale levels	256
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	200 x 100 DPI
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	- pages per month
Total input capacity	500 sheets
Total output capacity	250 sheets
Duplex media weight	60 - 120 g/m²
Paper tray media types	Envelopes
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Product color	Black, Grey
Market positioning	Business
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
Standard interfaces	Ethernet, USB 2.0
Memory slots	1
Internal memory	512 MB
Compatible memory cards	SD
Sound power level (standby)	53 dB
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	54.7 W
Power consumption (average operating)	680 W

Weight and Dimensions

Depth	455 mm
Width	475 mm
Height	575 mm
Weight	21500 g
