Utax P-4035 MFP Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6-1
2-1-3
List of correspondences of PWB names
No. Name used in service manual Name used in parts list Part.No.
1 Control PWB (CONPWB)
PARTS PWB ASSY CONTROLLER SP
302NY94020 *1,*4,*5
302P094020 *1,*3,*5
302NX94030 *1,*4,*6
302NZ94020 *1,*3,*6
302NM94040 *8
302P694020 *7
PARTS PWB ASSY CONTROLLER SP
EU
302NY94030 *1,*4,*5
302P094030 *1,*3,*5
302NX94040 *1,*4,*6
302NZ94030 *1,*3,*6
302NM94050 *8
302P694030 *7
2 Connect -Left PWB (C-LPWB) PARTS PWB ASSY CONNECT-L SP
302L294092 *1
302LV94192 *2
3 Connect-Right PWB (C-RPWB) PARTS PWB ASSY CONNECT-R SP
302NX94060 *1
302NM94070 *2
4 Operation panel PWB (OPPWB) *4 PARTS PWB ASSY H PANEL MAIN SP 302NM94080
5 Key-Left PWB (K-LPWB) *4 PARTS PWB ASSY H PANEL KEY-L SP 302NM94100
6 Key-Right PWB (K-RPWB) *4 PARTS PWB ASSY H PANEL KEY-R SP 302NM94090
7 High voltage PWB (HVPWB) PARTS HIGH VOLTAGE UNIT SP
302L294030 *1
302LV94060 *2
8 Power source PWB (PSPWB)
PARTS SWITCHING REGULATOR 120V
SP
302NX94050 *1
302LV94080 *2
PARTS SWITCHING REGULATOR 230V
SP
302L294040 *1
302LV94070 *2
9 Drum PWB (DRPWB)
P.W.BOARD ASSY DRUM
(DK-3100(U)) *1
(DK-3100(E)) *1
(DK-3100(AO)) *1
(DK-3130(U)) *2
(DK-3130(E)) *2
(DK-3130(AO)) *2
-
(302MS93042)
(302MS93022)
(302MS93052)
(302LV93062)
(302LV93042)
(302LV93072)
10 Drum connect PWB (DRCPWB)
PARTS PWB ASSY DRUM CONNECT
SP
302LV94200
11 Toner container PWB (TCONPWB)
P.W.BOAD ASSY CONTAINER
(TK-3100) *1
(TK-3102) *1
(TK-3104) *1
(TK-3122) *8
(TK-3130) *2
(TK-3132) *7
(TK-3134) *2
-
(1T02MS0NL0)
(1T02MS0US0)
(1T02MS0AS0)
(1T02L10US0)
(1T02LV0NL0)
(1T02LV0US0)
(1T02LV0AS0)

Utax P-4035 MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	40 cpm
Scan to	E-mail, File, Image, USB
Grayscale levels	256
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	200 x 100 DPI
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	- pages per month
Total input capacity	500 sheets
Total output capacity	250 sheets
Duplex media weight	60 - 120 g/m²
Paper tray media types	Envelopes
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Product color	Black, Grey
Market positioning	Business
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
Standard interfaces	Ethernet, USB 2.0
Memory slots	1
Internal memory	512 MB
Compatible memory cards	SD
Sound power level (standby)	53 dB
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	54.7 W
Power consumption (average operating)	680 W

Weight and Dimensions

Depth	455 mm
Width	475 mm
Height	575 mm
Weight	21500 g
