Utax P-4035 MFP Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
2-2-6
YC19
15 SCNT O 0/3.3 V DC Separation output control signal
Connected to
the high volt-
age PWB
16 TRREM O 0/3.3 V DC TC remote signal
17 TCNT O Analog TC control signal
18 +24V2_E1 O 24 V DC 24 V DC power output
YC21
1 TH2 I Analog FUTH2 output signal
Connected to
the fuser
thermistor
connect
PWB
2 TH1 I Analog FUTH1output signal
3 GND - - Ground
4 REARFANN O 24 V DC REFM: On/Off
5 +24V0_E3 O 24 V DC 24 V DC power output
YC22
1 +24V0_E1 O 24 V DC 24 V DC power output to PF
Connected to
the Paper
Feeder
(Option)
2 OPSDO O 0/3.3 V DC (pulse) PF communication serial data signal
3 OPSDI I 0/3.3 V DC (pulse) PF communication serial data signal
4 OPCLK O 0/3.3 V DC (pulse) PF communication serial clock signal
5 OPRDYN I 0/3.3 V DC Option communication ready signal
6 +3.3V1_E1 O 3.3 V DC 3.3 V DC power output
7 GND - - Ground
8 OPSEL2 O 0/3.3 V DC PF select signal
9 OPSEL1 O 0/3.3 V DC PF select signal
10 OPSEL0 O 0/3.3 V DC PF select signal
11 OPPAUSEN O 0/3.3 V DC Paper stop signal
12 GND - - Ground
YC26
1 +3.3V2_E2 O 3.3 V DC 3.3 V DC power output
Connected to
the eject sen-
sor
2 GND - - Ground
3 EXITSENSN I 0/3.3 V DC ES: On/Off
YC27
1 +24V0_E1 O 24 V DC 24 V DC power output
Connected to
the connect
right PWB
2 +24V0_E1 O 24 V DC 24 V DC power output
3 GND - - Ground
4 GND - - Ground
5 GND - - Ground
6 GND - - Ground
7 +24V2_E1 I 24 V DC 24 V DC power input
8 +24V2_E1 I 24 V DC 24 V DC power input
Connector Pin Signal I/O Voltage Description

Utax P-4035 MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	40 cpm
Scan to	E-mail, File, Image, USB
Grayscale levels	256
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	200 x 100 DPI
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	- pages per month
Total input capacity	500 sheets
Total output capacity	250 sheets
Duplex media weight	60 - 120 g/m²
Paper tray media types	Envelopes
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Product color	Black, Grey
Market positioning	Business
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
Standard interfaces	Ethernet, USB 2.0
Memory slots	1
Internal memory	512 MB
Compatible memory cards	SD
Sound power level (standby)	53 dB
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	54.7 W
Power consumption (average operating)	680 W

Weight and Dimensions

Depth	455 mm
Width	475 mm
Height	575 mm
Weight	21500 g
