Utax P-4035 MFP Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
2-2-7
YC29
1 DEEP_SLEEP
N
O 0/3.3 V DC Sleep signal
Connected to
the connect
right PWB
2 RFANH O 0/24 V DC RFM: On/Off
3 MPFSOL O 0/24 V DC MPSOL: On/Off
4 COVOPN
5 LIFTMOTOR O 0/5 V DC LM: On/Off
6 RFANL O 0/24 V DC RFM: On/Off
7 DLPCL O 0/3.3 V DC DEVCL: On/Off
8 DHEATER_R
EM
O 0/24 V DC DH: On/Off
9 FEEDCL O 0/24 V DC PFCL: On/Off
10 POWERSW I 0/3.3 V DC PSSW: On/Off
11 REGCL O 0/24 V DC RCL: On/Off
12 CASSET O Analog CSSW: On/Off
13 PSLEEPN I 0/5 V DC Sleep mode signal
14 MMOTCWN O 0/5 V DC MM drive shift signal
15 RELAY I 0/5 V DC Relay control
16 MMOTRDYN I 0/3.3 V DC MM ready signal
17 ZCROSSN O 0/5 V DC(pulse) Zero crossing signal
18 MMOTON O 0/5 V DC MM: On/Off
19 HEAT1REM O 0/24 V DC Fuser heater control
20 TYPE - - Not used
21 GND - - Ground
22 MMOTCLK O 0/5 V DC(pulse) MM clock signal
23 *1 GND - - Ground
24 *1 DMOTCLK O 0/5 V DC(pulse) DRM clock signal
25 *1 GND - - Ground
26 *1 DMOTRDYN I 0/3.3 V DC DRM ready signal
27 *1 MIDCL O 0/24 V DC PCCL: On/Off
28 *1 DMOTON O 0/5 V DC DRM: On/Off
29 *1 DUCL O 0/24 V DC DUCL: On/Off
30 *1 HEAT2REM O 0/24 V DC Fuser heater control
Connector Pin Signal I/O Voltage Description

Utax P-4035 MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	40 cpm
Scan to	E-mail, File, Image, USB
Grayscale levels	256
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	200 x 100 DPI
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	- pages per month
Total input capacity	500 sheets
Total output capacity	250 sheets
Duplex media weight	60 - 120 g/m²
Paper tray media types	Envelopes
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Product color	Black, Grey
Market positioning	Business
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
Standard interfaces	Ethernet, USB 2.0
Memory slots	1
Internal memory	512 MB
Compatible memory cards	SD
Sound power level (standby)	53 dB
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	54.7 W
Power consumption (average operating)	680 W

Weight and Dimensions

Depth	455 mm
Width	475 mm
Height	575 mm
Weight	21500 g
