ENGLISH
TECHNICAL DATA
AXIL-230V
AXIL-120V
Opening mechanical stop
Built-in trigger capacitor
AXIL-FC
Opening mechanical stop
Built-in trigger capacitor
O
pening electrical limit switch
AXIL-ECD
Opening mechanical stop
Built-in trigger capacitor
Encoder
AXIL-24V
Opening mechanical stop
Encoder
230V models 120V models 24V models
Max. leaf lenght m 2,8 2,8 2,8
Max. leaf weight Kg 300 300 300
Power supply Vac - Hz 230 - 50 120 - 60 24 Vdc
Idling current A 0,8 1,7 1,0
Full load current A 1,1 2,2 8
Maximum Power W 230 240 200
Capacitor µF 6,3 14 -
Max travel mm 350 350 350
Operating speed m/s 0,016 0,018 0,02 ÷ 0,012
Maximum thrust N 1700 1700 1700
Working temperature °C -30 ÷ +55 -30 ÷ +55 -30 ÷ +55
Protection IP 44 44 44
Working cycle % 35 30 60
Motor weight Kg 7,5 7,5 7,5
