VAC D500 - Parameter Descriptions: Digital Feedback; Switch 1 Configuration and Mask Map

65
Menu: Digital Feedback
Menu / parameter Value range Description
Input/Output / Digital Feedback
Switch 1 Switch 1 Funct.
Switch 1 Value
Switch 1 Logic
Switch 1 Active
The function of switch 1 is configured in this parameter group.
• Switch 1 Funct. – Switch 1 function
• Switch 1 Value – Switch 1 value
• Switch 1 Logic – Switch 1 logic
• Switch 1 Active – Switch 1 activation.
SW 1 Mask Map Alarm Maintenan.
Alarm OoSpec.
Alarm Check Fct.
Alarm Failure
Switch 1 Sim.
The function of switch 1 MASK MAP’ is configured in this parameter group.
• SW 1 Mask Map – Switch 1 diagnosis classification
• Switch 1 Sim. – Switch 1 simulation
Switch 2 Switch 1 Funct.
Switch 1 Value
Switch 1 Logic
Switch 1 Active
The function of switch 2 is configured in this parameter group.
• Switch 2 Funct. – Switch 2 function
• Switch 2 Value – Switch 2 value
• Switch 2 Logic – Switch 2 logic
• Switch 2 Active – Switch 2 activation.
• SW 2 Mask Map – Switch 2 diagnosis classification
• Switch 2 Sim. – Switch 2 simulation
SW 2 Mask Map Alarm Maintenan.
Alarm OoSpec.
Alarm Check Fct.
Alarm Failure
Switch 2 Sim.
The function of switch ‘2 MASK MAP’ is configured in this parameter group.
• SW 2 Mask Map – Switch 2 diagnosis classification
• Switch 2 Sim. – Switch 2 simulation
Menu: Switch 1
Menu / parameter Value range Description
Input/Output / Digit. Feedback / Switch 1
Switch 1 Funct. Position Info
Diagnostic State
Use this parameter to select whether the switch is to be used as a limit signal generator or for signaling
diagnostics messages.
• Position Info – Evaluate position
• Diagnostic State – Assess diagnosis status
Switch 1 Value 0 to 100% Use this parameter to configure the position value as a limit signal generator. It is taken into account
when the ‘Switch 1 Funct.’ parameter is set to ‘Position Info’.
Switch 1 Logic Active High
Active Low
Use this parameter to select the contact logic.
• Active High (active) = Output current I > 2.1 mA
• Active Low (active) = Output current I < 1.2 mA
Switch 1 Active Fall below, Exceeding Use this parameter to select the edge for activating the switch.
•
O
ff – Deactiva
ted
•
Fall below – If down-scaled
• Exceeding – If up-scaled
