VAC D500 - Parameter Descriptions: Digital Feedback Mask Maps; SW 1 and SW 2 Mask Map Settings

66
… 9 Operation
… Parameter descriptions
Menu: SW 1 Mask Map
Menu / parameter Value range Description
Input/Output / Digital Feedback / SW 1 Mask Map
Alarm Maintenan. On, Off When a general alarm is issued, an alarm current can be sent via the analog position feedback. These
alarm groups are defined in accordance with Namur NE107. Each individual group can be activated.
• Alarm Maintenan. – Maintenance needed
• Alarm OoSpec. – Operation outside specifications
• Alarm Check Fct. – Functional test needed
• Alarm Failure – Errors
Alarm OoSpec.
Alarm Check Fct.
Alarm Failure
Switch 1 Sim. Use this parameter to simulate the switch function.
• Off –Simulation deactivated
Menu: SW 2 Mask Map
Menu / parameter Value range Description
Input/Output / Digital Feedback / SW 2 Mask Map
Alarm Maintenan. On, Off When a general alarm is issued, an alarm current can be sent via the analog position feedback. These
alarm groups are defined in accordance with Namur NE107. Each individual group can be activated.
• Alarm Maintenan. – Maintenance needed
• Alarm OoSpec. – Operation outside specifications
• Alarm Check Fct. – Functional test needed
• Alarm Failure – Errors
Alarm OoSpec.
Alarm Check Fct.
Alarm Failure
Switch 1 Sim. Use this parameter to simulate the switch function.
• Off –Simulation deactivated
