vacon • 10 RECEIPT OF DELIVERY
Tel. +358 (0) 201 2121 • Fax +358 (0)201 212 205
3.2 NXC additional option codes
The NXC enclosure solution contains additional pre-engineered hardware options. These options
are appended to the basic type code by using “+” codes. The most common NXC options are listed
below:
3.2.1 Cabling (C-group)
3.2.2 External Terminals (T-group)
3.2.3 Input Device (I-group)
3.2.4 Main Circuit (M-group)
3.2.5 Output Filters (O-group)
3.2.6 Protection Devices (P-group)
+CIT Input (mains) cabling from TOP
+COT Output motor cabling from TOP
+TIO I/O+ aux terminals (35 pcs) X2
+TID I/O+ double aux terminals (70 pcs) Double-decker terminals X2
+TUP Separate terminals for 230 VAC CV X1
+ILS Load switch
+IFD Fused disconnecting switch With aR Fuses
+ICO Contactor
+IFU Fused With aR Fuses
+ICB Moulded-case or air circuit breaker
+MDC DC-bus bar connection Req. BSF converter hardware
+OCM Common mode choke Ferrite
+OCH Common mode choke
Nanoperm
®
+ODU dU/dt
+OSI Sine
+PTR Thermistor relay PTB certified
+PES Em. stop (cat 0) DI3
+PED Em. stop (cat 1) DI6 (sys.appl.)
+PAP Arc protection
+PIF Insulation fault sensor For IT-networks
