3.2.7 General (G-group)
3.2.8 Auxiliary Equipment (A-group)
3.2.9 Door Mounted (D-group)
+G40 400 empty cabinet
+G60 600 empty cabinet
+G80 800 empty cabinet
+GPL 100 mm base/plinth For 400 mm, 600 mm or 800 mm
+GPH 200 mm base/plinth For 400 mm, 600 mm or 800 mm
+AMF Motor fan control
+AMH Motor heater feeder
+AMB Mechanical brake control
+ACH Cabinet heater
+ACL Cabinet light
+ACR Control relay
+AAI Analogue signal isolator AI1, AO1, AI2
+AAC Aux. contact (input device) Wired to DI3
+AAA Aux. contact (control voltage devices) Chained to DI3
+ATx Aux. Transformer 400-690/230 VAC x = 1 (200 VA)
x = 2 (750 VA)
x = 3 (2500 VA)
x = 4 (4000 VA)
+ADC Power supply 24 VDC 10 A
+ACS 230 VAC customer socket With 30 mA leak current prot.
+DLV Pilot light (Control voltage on) 230 VAC
+DLD Pilot light (DO1) 24 VDC, DO1
+DLF Pilot light (FLT) 230 VAC, RO2
+DLR Pilot light (RUN) 230 VAC, RO1
+DAR Potentiometer for reference AI1
+DCO MC operation switch 0-1-START
+DRO Local / Remote op. switch Loc/Rem wired to DI6
+DEP Emergency stop push-button
+DRP Reset push-button DI6
+DAM Analogue meter (AO1) 48 mm, std scale 0-100%
+DCM Analogue meter + current
transformer
48 mm, std scale 0-600 A
+DVM Analogue vltg meter with sel.switch 0, L1-L2, L2-L3, L3-L1
