vacon • 82 CONTROL KEYPAD
Tel. +358 (0) 201 2121 • Fax +358 (0)201 212 205
9.3.6 System menu (M6)
The
System menu can be entered from the main menu by pushing the Menu button right when the
location indication M6 is visible on the display.
The controls associated with the general use of the frequency converter, such as application
selection, customised parameter sets or information about the hardware and software are located
under the
System menu . The number of submenus and subpages is shown with the symbol S (or P)
on the value line.
Functions in the System menu
Table 29. System menu functions
Code Function Min Max Unit Default Cust Selections
S6.1 Language selection English
Available selections depend
on the language package.
S6.2 Application selection
Basic
Application
Basic Application
Standard Application
Local/Remote control Appl.
Multi-Step Application
PID Control Application
Multi-Purpose Control Appl.
Pump and Fan Control Appl.
S6.3 Copy parameters
S6.3.1 Parameter sets
Store set 1
Load set 1
Store set 2
Load set 2
Load factory defaults
S6.3.2 Load up to keypad All parameters
S6.3.3
Load down from key-
pad
All parameters
All but motor parameters
Application parameters
P6.3.4 Parameter backup Yes
Yes
No
S6.4 Compare parameters
S6.4.1 Set1 Not used
S6.4.2 Set2 Not used
S6.4.3 Factory settings
S6.4.4 Keypad set
S6.5 Security
S6.5.1 Password Not used 0=Not used
P6.5.2 Parameter lock
Change
Enabled
Change Enabled
Change Disabled
S6.5.3 Start-up wizard
No
Yes
S6.5.4 Multimonitoring items
Change Enabled
Change Disabled
S6.6 Keypad settings
P6.6.1 Default page
P6.6.2
Default page/
Operating menu
P6.6.3 Timeout time 0 65535 s 30
P6.6.4 Contrast 0 31 18
P6.6.5 Backlight time Always 65535 min 10
S6.7 Hardware settings
