vacon • 24 MOUNTING
Tel. +358 (0) 201 2121 • Fax +358 (0)201 212 205
5.2 Lifting the unit out of the transport packaging
The unit is delivered either in a wooden box or a wooden cage. The box may be transported either
horizontally or vertically, while transportation of the cage in a horizontal position is not allowed.
Always refer to shipping marks for more detailed information. To lift the unit out of the box, use
lifting equipment capable of handling the weight of the cabinet.
There are lifting lugs on the top of the cabinet and these lugs can be used to lift the cabinet into an
upright position and to move it to the place needed.
Figure 3. Lifting the unit
NOTE! Location of lifting lugs varies between different frames.
Recycle the packaging material according to local regulations.
Min 60°
Min 60°
Min 60°
11484_00
