Vacon nxp/c User Manual

MOUNTING vacon • 23
24-hour support +358 (0)201 212 575 • Email: vacon@vacon.com
5
* the options +GPL or +GPH (Plinth) increase the height by 100mm or 200mm respectively
** some options, e.g. +CIT (Top input cabling +400mm), +COT (Top output cabling +400mm) and +ODU
(output du/dt filter +400mm) affect the width of the cabinet
Table 8. NXC 12-pulse drives cabinet dimensions
Type
Dimensions [mm] IP21 Dimensions [mm] IP54
W1 H1 D1 W1 H1 D1
0385—0520 5
0261—0416 6
606** 2275* 605 606** 2400* 605
0590—0730 5
0460—0590 6
806** 2275* 605 806** 2400* 605
0820—1030 5
0650—0820 6
1206** 2275* 605 1206** 2400* 605
1150 5
0920—1180 6
1406** 2275* 605 1406** 2400* 605
1300—1450 5 2006** 2275* 605 2006** 2400* 605
1770—2150 5
1500—2250 6
2806** 2275* 605 2806** 2400* 605
Table 9. NXC drive low-harmonic cabinet dimensions
Type
Dimensions [mm] IP21 Dimensions [mm] IP54
W1 H1 D1 W1 H1 D1
0261—0520 5
0125—0416 6
1006** 2275* 605 1006** 2405* 605
0590—1030 5
0460—0820 6
2006** 2275* 605 2006** 2405* 605
1150—1450 5
0920—1180 6
2206** 2275* 605 2206** 2445* 605
1770—2700 5
1500—2250 6
4406** 2275* 605 4406** 2445* 605
