Vacon nxp/c User Manual

CABLING AND CONNECTIONS vacon • 45
24-hour support +358 (0)201 212 575 • Email: vacon@vacon.com
6
6.2.6 Cable and fuse sizes, 380-500 V units
The table below shows typical cable sizes and types that can be used with the converter. The final
selection should be made according to local regulations, cable installation conditions and cable
specification.
6.2.6.1 6-pulse drives
Table 13. Cable and fuse sizes for Vacon NX_5, 6-pulse supply
Frame Type
I
L
[A]
Bussmann/Ferraz
Shawmut fuse type
Fuse I
n
[A]
Mains and motor
cable
1)
[mm
2
]
No. of
supply
cables
No. of
motor
cables
FR9
NXC0261 5 261
170M5813 (3 pcs)
NH2UD69V500PV (3 pcs)
700/500
Cu: 3*185+95 or
2*(3*120+70)
Even/Odd Even/Odd
NXC0300 5 300
170M5813 (3 pcs)
NH2UD69V500PV (3 pcs)
700/500 Cu: 2*(3*120+70) Even/Odd Even/Odd
FR10
NXC0385 5 385
170M5813 (3 pcs)
NH2UD69V700PV (3 pcs)
700
Cu: 2*(3*120+70)
Al: 2*(3*185Al+57Cu)
Even/Odd Even/Odd
NXC0460 5 460
170M8547 (3 pcs)
NH3UD69V1000PV (3 pcs)
1250/
1000
Cu: 2*(3*150+70)
Al: 2*(3*240Al+72Cu)
Even/Odd Even/Odd
NXC0520 5 520
170M8547 (3 pcs)
NH3UD69V1000PV (3 pcs)
1250/
1000
Cu: 2*(3*185+95)
Al: 2*(3*300Al+88Cu)
Even/Odd Even/Odd
FR11
NXC0590 5 590
170M5813 (6 pcs)
NH2UD69V700PV (6 pcs)
700
Cu: 2*(3*240+120)
Al: 4*(3*120Al+41Cu)
Even
2)
Even/Odd
NXC0650 5 650
170M5813 (6 pcs)
NH2UD69V700PV (6 pcs)
700
Cu: 4*(3*95+50)
Al: 4*(3*150Al+41Cu)
Even
2)
Even/Odd
NXC0730 5 730
170M5813 (6 pcs)
NH2UD69V700PV (6 pcs)
700
Cu: 4*(3*120+70)
Al: 4*(3*185Al+57Cu)
Even
2)
Even/Odd
FR12
NXC0820 5 820
170M8547 (6 pcs)
NH3UD69V1000PV (6 pcs)
1250/
1000
Cu: 4*(3*150+70)
Al: 4*(3*185Al+57Cu)
Even Even
NXC0920 5 920
170M8547 (6 pcs)
NH3UD69V1000PV (6 pcs)
1250/
1000
Cu: 4*(3*150+70)
Al: 4*(3*240Al+72Cu)
Even Even
NXC1030 5 1030
170M8547 (6 pcs)
NH3UD69V1000PV (6 pcs)
1250/
1000
Cu: 4*(3*185+95)
Al: 4*(3*300Al+88Cu)
Even Even
FR13
NXC1150 5 1150 No additional drive fuses needed
Cu:5*(3*150+70)
Al:6*(3*185+57Cu)
Even/Odd Even/Odd
NXC1300 5 1300 No additional drive fuses needed
Cu:5*(3*185+95)
Al:6*(3*240+72Cu)
Even/Odd Even/Odd
NXC1450 5 1450 No additional drive fuses needed
Cu:6*(3*185+95)
Al:6*(3*240+72Cu)
Even/Odd Even/Odd
FR14
NXC1770 5 1770 No additional drive fuses needed
Cu: 6*(3*240+120)
Al: 8*(3*240+72Cu)
Even Even
NXC2150 5 2150 No additional drive fuses needed
Cu: 8*(3*185+95)
Al: 8*(3*300+88Cu)
Even Even
1)
Based on correction factor 0.7. Cables are laid on a cable ladder side by side, three ladders on top of each
other. Ambient temperature is 30 °C (86 °F). EN60204-1 and IEC 60364-5-523.
2)
Odd number of supply cables possible on request. Please contact factory for more information.
