Vacon nxp/c User Manual

6
vacon • 50 CABLING AND CONNECTIONS
Tel. +358 (0) 201 2121 • Fax +358 (0)201 212 205
6.2.7.3 Low-harmonic drives
Table 18. Cable and aR fuse sizes for Vacon NX_6 low-harmonic drive
Frame Type
I
L
[A]
Bussmann / Ferraz
Shawmut fuse type
Fuse I
n
[A]
Mains and motor
cable
1)
[mm
2
]
No of
supply
cables
No of
motor
cables
AF9
NXC0125 6
NXC0144 6
NXC0170 6
NXC0208 6
125
144
170
No additional drive fuses needed Cu: 3*95+50 Even/Odd Even/Odd
208 No additional drive fuses needed Cu: 3*150+70 Even/Odd Even/Odd
AF10
NXC0261 6 261 No additional drive fuses needed
Cu: 3*185+95
Al: 2*(3*95Al+29Cu)
Even/Odd Even/Odd
NXC0325 6 325 No additional drive fuses needed
Cu: 2*(3*95+50)
Al: 2*(3*150Al+41Cu)
Even/Odd Even/Odd
NXC0385 6 385 No additional drive fuses needed
Cu: 2*(3*120+70)
Al: 2*(3*185Al+57Cu)
Even/Odd Even/Odd
NXC0416 6 416 No additional drive fuses needed
Cu: 2*(3*150+70)
Al: 2*(3*185Al+57Cu)
Even/Odd Even/Odd
AF12
NXC0460 6 460 No additional drive fuses needed
Cu: 2*(3*150+70)
Al: 2*(3*240Al+72Cu)
Even/Odd Even
NXC0502 6 502 No additional drive fuses needed
Cu: 2*(3*185+95)
Al: 2*(3*300Al+88 Cu)
Even/Odd Even
NXC0590 6 590 No additional drive fuses needed
Cu: 2*(3*240+120)
Al: 4*(3*120Al+41Cu)
Even/Odd Even
NXC0650 6 650 No additional drive fuses needed
Cu: 4*(3*95+50)
Al: 4*(3*150Al+41Cu)
Even/Odd Even
NXC0750 6 750 No additional drive fuses needed
Cu: 4*(3*120+70)
Al: 4*(3*150Al+41Cu)
Even/Odd Even
NXC0820 6 820 No additional drive fuses needed
Cu: 4*(3*150+70)
Al: 4*(3*185Al+57Cu)
Even/Odd Even
AF13
NXC0920 6 920 No additional drive fuses needed
Cu:4*(3*150+70)
Al:4*(3*2405+72Cu)
Even/Odd Even/Odd
NXC1030 6 1030 No additional drive fuses needed
Cu:4*(3*185+95)
Al:5*(3*185+57Cu)
Even/Odd Even/Odd
NXC1180 6 1180 No additional drive fuses needed
Cu:5*(3*185+95)
Al:6*(3*185+72Cu)
Even/Odd Even/Odd
AF14
NXC1500 6 1500 No additional drive fuses needed
Cu:6*(3*185+95)
Al:8*(3*185+57Cu)
Even/Odd Even
NXC1900 6 1900 No additional drive fuses needed
Cu:6*(3*240+120)
Al:8*(3*240+72Cu)
Even Even
NXC2250 6 2250 No additional drive fuses needed
Cu:8*(3*240+120)
Al:8*(3*300+88Cu)
Even Even
1)
Based on correction factor 0.7. Cables are laid on a cable ladder side by side, three ladders on top of each
other. Ambient temperature is 30 °C (86 °F). EN60204-1 and IEC 60364-5-523.
