vacon • 44 Descriptions of VACON® option boards

Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/

I/O terminals on OPTAL

Table 17. OPTAL I/O terminals

Terminal

Parameter reference

Keypad/NCDrive

Technical information

1 +15 V 15 V out – together with terminal 2 max 200 mA

2 +15 V 15 V out

3 AI1 An.IN:A.1 Analog input 0 – 10 V

4 AI2 An.IN:A.2 Analog input ± 10 V

5 GND Ground for analog signals

6 AO1+ AnOUT:A.1 Analog output 0 (4) – 20 mA

7 AO2+ AnOUT:A.2 Analog output 0 – 10 V

8 DO1 Open collector digital output , 48 V, 50 mA allowed

9 GND Ground for analog signals

10 + 24 V 24 V out – max 200 mA

ACIN1 DigIN:X.1
