8000026412_01 Air/flue pipe installation manual 7
3 Certified air/flue systems and components
3.1 System overview, 60/100 mm diameter – products until 2024
Article number Air/flue systems, concentric
A 0020223472 Vertical roof duct (black, RAL 9005), with collar
B 303982 Vertical ridge roof duct
C 0020228140¹ Direct, rear-side, telescopic flue system
D
0020219517¹ Horizontal wall duct, 0.7 m
0020219519¹ Horizontal wall duct, 1.7 m
E 0020219518¹ Horizontal telescopic wall duct (only available in black)
F 0010035512² Horizontal wall duct, 0.7 m for multi-storey buildings
G 0010024718² Horizontal wall duct, for balcony installation and for installing the variable terminal set (VTK) in multi-storey
buildings
H 303933¹ Horizontal wall duct, 0.7 m
1) In accordance with the construction regulation, installation in buildings higher than 18 m (11 m in Scotland) is not permitted.
2) In accordance with the construction regulation, installation in buildings higher than 18 m (11 m in Scotland) is permitted.
The following table lists the air/flue systems that are permitted as part of the system certification, along with their certified
components.
3.1.1 Components
The following table lists the air/flue systems that are permitted as part of the system certification, along with their certified
components.
Optional connection accessories Article num-
ber
A B C D E F G H
Extension (PP), concentric, 470 mm, 60/100 mm diameter 303902 X X X X X X X
Extension (PP), concentric, 970 mm, 60/100 mm diameter 303903 X X X X X X X
Extension (PP), concentric, 1970 mm, 60/100 mm diameter 303905 X X X X X X X
Extension (PP), concentric, 3960 mm, 60/100 mm diameter 0020138174¹ X X X X X X X
45° elbow (2 pcs), concentric 303911 X X X X X X X
87° elbow, concentric 303910 X X X X X X X
Pipe clamp (5 pcs), 100 mm diameter 303821 X X X X X X X
Adjustable pipe clamps (3 pcs), 100 mm diameter 303935 X X X X X X X
Sliding sleeve 303915 X X X X X X X
Pitched roof tile 009076
(black)
X
Universal pitched roof tile 303980 X
Flat roof penetration collar 009056 X
Telescopic extension, 440-690 mm, 60/100 mm diameter 303906 X X X X X X X
Telescopic offset piece 303919 X X
Black terminal set for horizontal air/flue pipe 0020219537 X
Variable terminal set (VTK), black 0020219529² X X X
Variable terminal set (VTK), white 0020219530² X
Extension for variable terminal set (VTK), 60 mm diameter, 1 m, black 0020219539² X X X
Extension for variable terminal set (VTK), 60 mm diameter, 1 m, white 0020219540² X
87° elbow for variable terminal set (VTK), black 0020219543² X X X
87° elbow for variable terminal set (VTK), white 0020219544² X
45° elbow (2 pcs) for variable terminal set (VTK), black 0020219551 X X X
45° elbow (2 pcs) for variable terminal set (VTK), white 0020219552 X
Deflector set, DN 60, PP, black 0020219533 X X X
Deflector set, DN 60, PP, white 0020219534 X
1) To reduce the pipe connections that need to be inspected, 4 m extensions are offered on request. (Special delivery with minimum
purchasing quantity. No returns accepted.) The required downward gradient is also 3°. A height of 224 mm is therefore required for the
4 m extension. Take the height into consideration when selecting the installation site.
2) Delivery with pipe clamps
