6. Using probe with Indigo transmitters
Indigo transmitters are host devices that extend the feature set of connected probes with a
range of additional options for outputs, configuration access, measurement viewing, and
status monitoring.
Available features vary depending on the transmitter model. Models without display use a LED
indicator for notifications.
6.1 Indigo200 series transmitters
Indigo200 series transmitters have a probe connector where compatible probes can be
attached directly. A cable may also be used to connect the probe.
After connecting the probe, use the wireless configuration interface to configure the
transmitter.
1
2
3
4
5
6
Figure 25 Probe attached to Indigo200 series transmitter directly
1
3.5” TFT LCD color display: non-display option with LED available for certain models
2 Locking wheel: insert probe, hold in place, and turn the wheel counterclockwise
3 Cable to probe head
4 Wireless configuration interface (WLAN) activation button
5 Rubber lead-through with strain relief. Cable feedthrough option also at back of
transmitter.
6 Input/output cable
