Options Compa II series
68 Operating manual 07.15
Press key
to arrive the next parameter.
Stroke adjust
The arrester can be adjusted and the stroke speed can be set. The
pad makes a stroke movement and return again to the basic position
after reaching the lower end position.
Press key
to start the stroke movement.
Press key
to arrive the next parameter.
This menu serves for the applicator setup as well as for error tracing.
Input signals of the applicator can be monitored and output signals
can be set or reset separately. With keys
and the
corresponding output for setting and/or resetting the output signals
can be selected. With keys
and the corresponding output can
be set or reset.
Input signals
I
1
= Pre-dispense key
(1 = key pressed, 0 = key not pressed)
I
2
= Final position up
(1 = pad in final position up, 0 = pad not in final position up)
I
3
= Final position down
(1 = pad in final position down,
(0 = pad not in final position down)
I
4
= Compressed air
(1 = compressed air available,
(0 = no compressed air available)
I
5
= Vacuum
(1 = vacuum at pad available, 0 = no vacuum at pad available)
Output signals
O
1
= Move pad downwards (1 = On, 0 = Off)
O
2
= Move pad upwards (1 = On, 0 = Off)
O
3
= not assigned
O
4
= not assigned
O
5
= Blowing air (1 = On, 0 = Off)
O
6
= Supporting air (1 = On, 0 = Off)
O
7
= Vacuum pad (1 = On, 0 = Off)
Test functions
Input/Output
