CAP. 11 - AUTOMATIC CYCLES 46 / 74 ENGLISH
ClimFill Maxi
11.3.3 User-defined cycles
It allows loading the parameters of the automatic cycle previously saved by the user.
11.3.4 Search parameters by vehicle registration plate number
It allows loading the parameters of the automatic cycle previously saved for a specific
vehicle identified by its registration plate number.
11.3.5 Automatic cycle parameters configuration
After selecting the type of A/C system, the main page is shown with the following preset
values:
• amount of refrigerant that will be charged into the system and the amount of
refrigerant contained in the inner tank of the product.
• Injection mode and quantity of oil that will be injected into the system
o OIL: <value> g. It injects the quantity of oil that has been set.
o REC. + <value> g. It injects the quantity of recovered oil plus the quantity
of oil that has been set
o NO OIL. No oil is injected during the injection cycle
• Oil type: It sets the oil type being used. PAG (ISO46/100/150) or POE (see next
paragraph)
• UV: Option for the injection of detection dye
• Injection type: It allows selecting from which hose the service is carried out,
according to the type of system.
o Injection from HP hose (red)
o Injection from LP hose (blue)
o Injection from HP hose (red) and LP hose (blue)
o Injection from HP hose (red) on the system low pressure side. Specific for
some Renault models.
o Vacuum phase
Vacuum duration
Leak test duration
o Refrigerant vessel heating phase with heating belt
Yes
No
At the end of each automatic cycle, the equipment asks to fill in report data for
printing.
