CAP. 12 - MANUAL CYCLES 48 / 74 ENGLISH
ClimFill Maxi
CAP. 12 - MANUAL CYCLES
12.1 PRELIMINARY OPERATIONS
It is necessary to connect both the LP (low pressure) – and HP (high pressure) couplers
to the vehicle A/C system (Screw the valves only when required by the A/C station).
12.2 RECOVERY
In the main menu, select MANUAL CYCLES and then the RECOVERY function. (For the
touchscreen use, see chap. 5,11)
Press and start the recovery function and follow the equipment instructions. If there is no
pressure inside the system, this function cannot be started.
POSSIBLE ERROR INDICATION
Too high pressure in the A/C service unit.
Valves or couplers closed or system empty.
12.3 VACUUM PHASE
From the main menu, select MANUAL CYCLES and press VACUUM.
(For the touchscreen use, see chap. 5.11). Connect the HP – LP couplers or the single
coupler to the vehicle system and screw the couplers. Now set the vacuum time and
the test duration and whether you want to activate the heating belt during this phase.
The vacuum phase is automatically followed by the “vacuum test” phase.
Press START to start the vacuum phase.
POSSIBLE ERROR INDICATION
System pressurised
POSSIBLE ERROR INDICATION
System not tight
