CAP. 13 - MAINTENANCE 56 / 74 ENGLISH
ClimFill Maxi
5. Unscrew the bolts securing the rear door.
Position of the rear door.
Position of the fixing screws to be unscrewed using a cross-tip screwdriver.
6. Remove the strap that winds up the filter
7. Unscrew the 2 connection nuts of the filter by means of the hex keys.
Unscrew the upper nut of the filter using a 24-mm and 17-mm hex key in order to block the
filter and lever with it as shown in the next photo.
Be careful; pay the highest attention in order not to deform the hoses permanently.
DRYER FILTER
