8.4. Serial communication connection
The device can be equipped with optional communication
module. The physical location of the module is the lower option
card slot at the back of the relay. The modules can be installed
in the field (when power is first turned off).
There are three “logical communication ports” available in the
relay: REMOTE, LOCAL and EXTENSION. Depending on the
module type one or more of these ports are physically available
at the external connectors.
8.4.1. Pin assignments of communication options
The communication module types and their pin assignments
are introduced in the following table.
Type
Order code, Name
Communication
ports
Signal
levels
Connectors
Pin usage
VCM
232+00
VCM
232+IR
VCM
232+FI
VCM
232+I62
VCM
232+L6
LA
RS-232 interface
REMOTE
RS-232
D-
connector
2 = TX_REM
3 = RX_REM
7 = GND
9 = +12V
LB
RS-232 interface
with
timesyncronisation
input
CLOCK SYNC
(IRIG-B )
TTL
2-pole
screw
connector
1= Data
2= GND
LC
RS-232 interface
with RTD fiber optic
interface
EXTENSION
RTD protocol
must be selected
for the port
Light
Snap-in
connector
LE
RS-232 interface
including IEC 61850
interface
ETHERNET
Ethernet
10Mbps
RJ-45
1=Transmit+
2=Transmit-
3=Receive+
4=Reserved
5=Reserved
6=Receive-
7=Reserved
8=Reserved
LG
RS-232 interface
including IEC 61850
Ethernet fibre
interface
ETHERNET
Light
100Mbps
LC-
connector
TX=Lower
LC-connector
RX=Upper
LC-connector
