VAMP 59 - Circuit-Breaker Failure Protection; Arc Fault Protection (Option)

Technical description
9 Technical data
9.3 Protection stages
VM59.EN001
VAMP 24h support phone +358 (0)20 753 3264
201
9.3.3. Circuit-breaker failure protection
Circuit-breaker failure protection CBFP (50BF)
Relay to be supervised
T1, T2, T3 and T4
Definite time function
- Operating time
0.1** – 10.0 s (step 0.1 s)
Inaccuracy
- Operating time
±100 ms
**) This is the instantaneous time i.e. the minimum total operational time including the fault
detection time and operation time of the trip contacts.
9.3.4. Arc fault protection (option)
The operation of the arc protection depends on the setting value
of the ArcI> and ArcI
01
> current limits. The arc current limits
cannot be set, unless the relay is provided with the optional arc
protection card.
Arc protection stage ArcI> (50ARC), option
Setting range
0.5 - 10.0 x I
N
Arc sensor connection
S1, S2, S1/S2, BI, S1/BI, S2/BI, S1/S2/BI
- Operating time (Light only)
13 ms
- Operating time (4xIset + light)
17ms
- Operating time (BIN)
10 ms
- Operating time (Delayed Arc L>)
0.01 – 0.15 s
- BO operating time
<3 ms
Reset time
<95 ms
Reset time (Delayed ARC L)
<120 ms
Reset time (BO)
<85 ms
Reset ratio
0.90
Inaccuracy:
- Starting
10% of the set value
- Operating time
±5 ms
- Delayed ARC light
±10 ms
ArcIo Arc protection stage ArcI
01
> (50NARC), option
Setting range
0.5 - 10.0 x I
N
Arc sensor connection
S1, S2, S1/S2, BI, S1/BI, S2/BI, S1/S2/BI
- Operating time (Light only)
13 ms
- Operating time (4xIset + light)
17ms
- Operating time (BIN)
10 ms
- Operating time (Delayed Arc L>)
0.01 – 0.15 s
- BO operating time
<3 ms
Reset time
<95 ms
Reset time (Delayed ARC L)
<120 ms
Reset time (BO)
<85 ms
Reset ratio
0.90
Inaccuracy:
- Starting
10% of the set value
- Operating time
±5 ms
- Delayed ARC light
±10 ms
