VAMP 59 - Digital Inputs; Trip Contacts; Alarm Contacts; Local Serial Communication Port

9.1 Connections
9 Technical data
Technical description
192
VAMP 24h support phone +358 (0)20 753 3264
VM59.EN001
9.1.3. Digital inputs
Internal operating voltage
Number of inputs
2
External operating voltage
Rated voltage selectable in order code:
A: 24 V dc / 110V ac
B: 110 V dc / 220V ac
C: 220 V dc
Current drain
approx. 2 mA
Activation time dc/ac
< 11 ms / < 15 ms
Reset time dc/ac
< 11 ms / < 15 ms
Terminal block:
Maximum wire dimension:
- Phoenix MVSTBW or equivalent
2.5 mm2 (13-14 AWG)
Note! A-option DI activation/reset V: dc ≈ 15 / 10, 50 Hz ≈ 100 / 5, 60 Hz ≈ 85 / 5
B-option DI activation/reset V: dc ≈ 95 / 85, 50 Hz ≈ 200 / 60, 60 Hz ≈ 180 / 60
C-option DI activation/reset V: dc ≈ 185 / 175
9.1.4. Trip contacts
Number of contacts
4 making contacts (relays T1, T2, T3, T4)
Rated voltage
250 V ac/dc
Continuous carry
5 A
Make and carry, 0.5 s
Make and carry, 3s
30 A
15 A
Breaking capacity, DC (L/R=40ms)
at 48 V dc:
at 110 V dc:
at 220 V dc
5 A
3 A
1 A
Contact material
AgNi 90/10
Terminal block:
Maximum wire dimension:
- Phoenix MVSTBW or equivalent
2.5 mm
2
(13-14 AWG)
9.1.5. Alarm contacts
Number of contacts:
2 change-over contacts (relays A1 and IF)
Rated voltage
250 V ac/dc
Continuous carry
5 A
Breaking capacity, DC (L/R=40ms)
at 48 V dc:
at 110 V dc:
at 220 V dc
1,3 A
0,4 A
0,2 A
Contact material
AgNi 0.15 gold plated
Terminal block
Maximum wire dimension
- Phoenix MVSTBW or equivalent
2.5 mm
2
(13-14 AWG)
9.1.6. Local serial communication port
Number of ports
1 on front
Electrical connection
USB
Data transfer rate
2 400 - 187 500 kb/s
