8.5 Optional digital input / output
card
VAMP 24h support phone +358 (0)20 753 3264
Figure 8-3 AC mode selection in VAMPSET
How to select the threshold of digital inputs when the DI/DO –
option card is ordered separately and not modified at the
factory:
Figure 8-4 Option 1: 24Vdc / 110Vac
Figure 8-5 Option 2: 110Vdc / 220Vac
Figure 8-6 Option 3: 220Vdc
