VAMP 59 - Page 96

2.14 Inverse time operation
2 Protection functions
Technical description
96
VAMP 24h support phone +358 (0)20 753 3264
VM59.EN001
Figure 2.14.1-5 ANSI/IEEE long time inverse
delay
Figure 2.14.1-6 ANSI/IEEE long time very
inverse delay
Figure 2.14.1-7 ANSI/IEEE long time
extremely inverse delay
Figure 2.14.1-8 ANSI/IEEE moderately
inverse delay
