WRM-10P/WRM-40 OPERATING INSTRUCTIONS
8
Table 2.0 Functional Descriptions of WRM-10P Controls and Indicators Cont
Fig. 1
Index
Panel Markings
Functional Descriptions
10
HIGH VOLTAGE
PRESENT
Red LED indicator light. When lit, this
indicator warns operators that there is a
possibility that voltage exists across test leads.
Do not disconnect test leads when this light is
on. Failure to heed this warning can result in
shock and/or fatal injury to personnel.
11
V2
Voltage sensing input channel #2. Test
connector jacks, female, for connecting voltage-
sensing test leads.
