10. Click the 1 Point Bright Calibration data file on View16 and make sure that the Median value
meets the standard.
※ Bright standard value: 5 points with Cu 1 mm filter
Bright Min Max
Median
value
Cal Point 1 50 80
Cal Point 2 80 200
Cal Point 3 200 400
Cal Point 4 400 600
Cal Point 5 601 ~
If the median value does not meet the requirement, do the steps that follow:
Click the Settings tab.
Adjust kVp0 value by 10 in the [BrightCalibration] field.
Click the Save button.
Acquire Bright calibration data again.
11. Click the 5 Point Bright Calibration data file on View16 and make sure that the Median value
meets the standard.
If the median value does not meet the requirement, do the steps that follow:
Click the Settings tab.
Adjust kVp1 value by 10 in the [BrightCalibration] field.
Click the Save button.
Acquire Bright calibration data again.
• From the achieved PANO Sensor Bright Calibration data file, the 1
Point Bright Data file and 5 Point Bright data file should meet the
standard value. Another result from different points Bright Datafile
can be varied by the characteristics of each sensor.
